Vortex Flowmeter(ZJX-PA-F-A3)
Model：ZJX-PA-F-A3
Description：
ZJX-PA-F-A3 vortex street flowmeter, according to the Karman vortex street phenomenon, when the medium flows through a triangular cylindrical vortex generator at a certain speed, two alternating rows of vortices are formed on both sides. The frequency of this vortex is proportional to the flow velocity of the fluid, and the vortex street frequency is converted into a standard electrical signal output
Capable of measuring the volumetric and mass flow rates of steam, gas, and liquid, while achieving the goals of measurement and control
Available in both integral and split structures, allowing for horizontal, vertical, and inclined installation at different angles
Strong electromagnetic interference resistance, low requirements for front and rear straight pipe sections
During the measurement process, it is almost unaffected by parameters such as fluid density, pressure, temperature, viscosity, etc
Multiple installation methods and output signals can be selected
Wide measurement range, with a ratio of 1:20 and low pressure loss
High temperature resistance (-40 ℃ -350 ℃), zero drift free, stable performance
Backlit LCD displays temperature, pressure, instantaneous flow rate, and cumulative flow rate, and the page can be switched between Chinese and English
Adopting differential technology, combined with measures such as isolation, shielding, and filtering, to solve seismic and signal problems
Using EEPROM for power-off protection of accumulated flow, with a duration greater than 10 years
Support OEM/ODM customization
Petroleum and chemical industry
Steel, Metallurgy
Food and Beverage
Medical, pharmaceutical
Civil engineering, building materials
Sewage treatment, water conservancy irrigation
Farmland, electricity
Environmental protection equipment and construction machinery
Paper making and mining machinery
Gas pipeline network, fire protection, scientific research
Gas, heating, air conditioning systems
Textile machinery, fire protection
