Turbine Flowmeter(ZJX-PA-F-A2)
Model：ZJX-PA-F-A2
Description：
The ZJX-PA-F-A2 turbine flowmeter uses rotating blades to cut magnetic lines of force, periodically changing the magnetic flux of the coil. Electric pulse signals are sensed at both ends of the coil, which are amplified and processed by the circuit to form pulse waves. Finally, through intelligent circuit processing, they are converted into instantaneous flow and cumulative flow. At the same time, the medium density is input to perform mass flow measurement
It can be used to measure non oil severely corroded media such as pure water and oil
Matched with instruments, it can perform quantitative control and over quantity alarm, suitable for use in trade settlement
No zero drift, low pressure loss, suitable for high-pressure measurement
Fully isolated design structure, with multiple output signals to choose from
Multiple installation methods available for selection
Multiple liquid receiving materials available for selection
Good repeatability, accuracy up to 0.2%, effective filtering of clutter, three circuit impact protection mode
Wide measurement range, with a range ratio of 1:20
Integrated turbine, no welding required, no false signals present
Spectrum signal processing, anti strong interference
High and low temperature experiments, temperature resistance testing, to ensure product reliability
The impeller is made of non magnetic stainless steel, finely milled and formed, with signal coefficient calibration, friction coefficient adjustment, speed increase/decrease, and measurement coefficient adjustment
Support OEM/ODM customization
Petroleum and chemical industry
Steel, Metallurgy
Food and Beverage
Medical, pharmaceutical
Civil engineering, building materials
Sewage treatment, water conservancy irrigation
Farmland, electricity
Environmental protection equipment and construction machinery
Paper making and mining machinery
Gas pipeline network, fire protection, scientific research
Gas, heating, air conditioning systems
Textile machinery, fire protection
