Explosion Proof Differential Pressure Transmitter (ZJX-PA-DP)
Model：ZJX-PA-DP
Description：
The ZJX-PA-DP Explosion proof high-precision differential pressure transmitter adopts a single crystal silicon sensor chip and a double beam suspension design achieving high accuracy, high overvoltage, and high stability performance. It is embedded with an intelligent signal processing module achieving an effective combination of static pressure and temperature compensation.
Configure the HART communication protocol for FSK technology
The HART communication protocol can communicate with the control system or manual operator
Accuracy: ± 0.075%, adjustable range greater than 10:1
Fast response speed, small error, and strong anti-interference performance
Can simultaneously measure the pressure, liquid level, or density of liquids, gases, and vapors
Adopting full fusion welding and rigid sealing structure
Local zero and full point calibration functions, as well as built-in positive and negative transfer function
Adopting a concave arc overload protection structure
Integrate high sensitivity components to effectively solve thermal drift
Support OEM/ODM customization
Hazardous explosion-proof areas
Oil and gas
Environmental/Pharmaceutical
Chemical/Paper Industry
Sewage disposa/HVAC
Printing and dyeing/electricity
Steel/Building Materials
Plastic/chemical fiber
